Description
The TTP Series of 2-inch desktop thermal transfer printers brings TSC quality, innovation, performance, reliability, and value to the small footprint 2-inch wide printer market.
The TTP-225 Series delivers premium performance for most retail, medical and office applications at an affordable price. The TTP-225 features a user-friendly clamshell design with a large 5-inch OD centre-biased media capacity. Designed with no loose parts, it is the perfect size when you need a space-saving printer for 2-inch wide labels or tags. Simply open the cover and drop your labels into the printer’s spring-loaded media guide. Top-of-form sensing by gap, black mark, or notch is standard and completely adjustable from side to side.
Choose either standard 203 dpi or higher resolution 300 dpi solutions.
The TTP-225 features 203 dpi resolution and print speeds up to 5 inches per second.
The 300 dpi TTP-323 is ideal for 2-D barcodes, fine text, and small graphics labelling.
The TTP-225 is one of the first low-cost thermal transfer compact 2-inch desktop printers to offer an optional LCD display to its customers. The LCD is used to present important information about print job status and setup which brings a new level of ease of use to its customers. Other outstanding features include an inexpensive internal Ethernet adapter for easy integration into network systems, cutters, a label present sensor, and an optional keyboard for printing labels in stand-alone or downtime situations.
- Retail Point-of-Sale
- Oil Change & Auto Service Labeling
- Pharmacy Prescription Labeling
- Healthcare Specimen Labeling
- Healthcare Patient Tracking
- Shelf Labelling
- Product Marking
- Inventory & Asset Management
- Small Office/Home Office Mailing
- File-Folder Labeling
- Wristbands
STANDARD CONFIGURATION:
Thermal transfer label printer
8MB SDRAM 4MB Flash
RS-232
USB 2.0
MicroSD card slot for memory expansion
STANDARD ACCESSORIES:
Windows labelling software CD
Quick Installation Guide (QIG)
USB cable
Power cord & External universal switching power supply
Hardware Specifications
TTP-225 |
TTP-323 |
|
| Resolution | 203 dpi (8 dots/mm) | 300 dpi (12 dots/mm) |
| Print Method | Direct thermal/Thermal transfer | Direct thermal/Thermal transfer |
| Display | LCD with buttons LED with buttons |
LCD with buttons LED with buttons |
| Hardwire Connectivity | Ethernet Serial RS-232 USB USB Host |
Ethernet Serial RS-232 USB USB Host |
| Wireless Connectivity | Bluetooth | Bluetooth |
| Enterprise Printer Management | TSC Console | TSC Console |
| Type | Desktop | Desktop |
| Max. Print Speed | Up to 5 ips (127 mm/s) | Up to 3 ips (76 mm/s) |
| Max. Print Width | 2.13″ (54 mm) | 2.13″ (54 mm) |
| Max. Print Length | 90″ (2;286 mm) | 40″ (1;016 mm) |
| RAM | 4 MB SDRAM | 4 MB SDRAM |
| Flash | 8 MB | 8 MB |
| Expandable Flash | microSD card reader; up to 4 GB | microSD card reader; up to 4 GB |
| Keyboard | Standalone keyboard | Optional keyboard |
| Optional Cutter | Guillotine cutter (full cut and partial cut) | Cutter |
Media Specifications
| Internal Label Capacity | 5″ (127 mm) OD | 5″ (127 mm) OD |
| Max. Media Width | 0.59″ – 2.36″ (15 – 60 mm) | 0.59″ – 2.36″ (15 – 60 mm) |
| Media Type | Continuous; Die-Cut; Black Mark; Fan-Fold; Notched; Wristband (Outside Wound) | Continuous; Die-Cut; Black Mark; Fan-Fold; Notched; Wristband (Outside Wound) |
| Max. Ribbon Length | 90 Meters | 90 Meters |
| Ribbon Width | 2.20″ – 2.28″ (56 – 58 mm) | 2.20″ – 2.28″ (56 – 58 mm) |
| Media Core Diameter | 1″ – 1.5″ (25.4 – 38 mm) | 1″ – 1.5″ (25.4 – 38 mm) |
| Construction | Clamshell with double-walled plastic | Clamshell with double-walled plastic |
| Programming Languages | TSPL-EZD | TSPL-EZD |
